Description
Ingersoll Rand BMDLN-4 Medium-Duty Spring Balancer reduces the risk of musculoskeletal injuries in tool operators by supporting the tool. This simple mechanism made from high quality strengthened material is suspended above the operator's workstation and attached to their tool via a retractable cable. The cable holds the weight of the tool, meaning your operator only has to direct its movement, not support the tool’s weight. This Medium-Duty spring balancer provides constant tension on the cable, accomplished with a spring motor and a steel drum. The balancer extends or retracts the support cable to follow the tool's movements. The assembler can reposition the tool while experiencing comfortable operation.
Load Capacity: 4.4-8.8 lb / 2-4 kg | Weight: 6.4 lb / 2.9 kg | Lift: 8.2 ft / 2,500 mm
| Model | BMDLN-4 |
| Weight of Balancer lb (net - kg) | 6.4 (2.9) |
| Lift ft (mm) | 8.2 (2500) |
| Capacity, lbs (kg) | 4.4 - 8.8 (2.0 - 4) |
- Rugged construction, cast aluminum body.
- Stainless steel cable.
- Adjustable capacity.
- Safety device against load dropping due to the spring breakage (>3kg).
- Adjustable stroke limiting device.
- Cable guide in anti-friction material.
For more information on the Ingersoll Rand BMDLN-4 please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 45648342
