CP7727 Pistol Grip 3/8" Air Impact Wrench | 185ft.lbs | by Chicago Pneumatic

CP7727 - More Compact, lighter, more powerful and durable than competition

Part number	8941077270
Model	CP7727
Handle type	Pistol
Square drive	3/8"
Working Torque Range (fwd)	26-192 Nm	20-140
Working Torque Range (fwd)	20-140 ft.lbs	26-192
Maximum Torque (reverse)	250 Nm	185 ft.lbs
Maximum Torque (reverse)	185 ft.lbs	250 Nm
Free speed	8510 rpm
Blows per minute	1600
Net weight	2 1/2 lb	1.12 kg
Net weight	1.12 kg	2 1/2 lb
Length	9.4"	240 mm
Length	240 mm	9.4"
Side to center	30 mm	1.18"
Side to center	1.18"	30 mm
Average air consumption	4 cfm
Average air consumption	1.9 l/s	4 cfm
Actual air consumption	16 cfm
Actual air consumption	7.4 l/s	16 cfm
Free speed air consumption	11.45 l/s
Air inlet thread size	0.25 "
Min. hose size	10 mm	3/8"
Min. hose size	3/8"	10 mm
Noise level	93 db(A)
Sound Power	104 db(A)
Vibration α (ISO-28927-2)	10.3 m/s²
Vibration K (ISO-28927-2)	1.3 m/s²
Socket retainer	Friction ring
Clutch type	Jumbo
Box dimensions	292*100*67

Benefits

High Durability

Compact

Powerful

Comfort

Great Control

Easy Operation

Single handed Forward / Reverse operation

3 positions in forward and 1 in reverse

Features

Jumbo hammer mechanism

Steel motor

Composite cover

Direct drive transmission mechanism

9.8 in -240 mm length and 3.46 in. (88 mm) height

220 ft.lbs - 300 Nm of maximum torque in reverse (for 1/2'' model)

2.46 lbs. / 1.12 Kg

Over molded composite and ergonomic handle to fit perfectly in hand

Full teasing trigger

Single handed Forward / Reverse operation

3 positions in forward and 1 in reverse

Socket retainer ring
