CP7748 Pistol Grip  1/2" Air Impact Wrench | 920 ft.lbs | by Chicago Pneumatic

CP7748 - Durable, Powerful & Ergonomic

Part number	8941077480
Model	CP7748
Handle type	Pistol
Square drive	1/2"
Working Torque Range (fwd)	102-786 Nm	75-580
Working Torque Range (fwd)	75-580 ft.lbs	102-786
Maximum Torque (reverse)	1250 Nm	920 ft.lbs
Maximum Torque (reverse)	920 ft.lbs	1250 Nm
Free speed	8200 rpm
Blows per minute	1200
Net weight	4.6 lb	2 kg
Net weight	2 kg	4.6 lb
Power/weight ratio	625 Nm/kg	200.4 ft.lb/lb
Power/weight ratio	200.4 ft.lb/lb	625 Nm/kg
Length	7.8"	200 mm
Length	200 mm	7.8"
Side to center	38 mm	1 1/2"
Side to center	1 1/2"	38 mm
Average air consumption	6.2 cfm
Average air consumption	3 l/s	6.2 cfm
Actual air consumption	25 cfm
Actual air consumption	12 l/s	25 cfm
Air inlet thread size	0.25 "
Min. hose size	10 mm	3/8"
Min. hose size	3/8"	10 mm
Noise level	93 db(A)
Sound Power	104 db(A)
Vibration α (ISO-28927-2)	10.1 m/s²
Vibration K (ISO-28927-2)	2.34 m/s²
Socket retainer	Friction ring
Clutch type	Twin Hammer
Box dimensions	215*210*77	8,5*8,25*3,03
Box dimensions	8,5*8,25*3,03	215*210*77
Over carton	455*420*240	17,9*16,5*9,45
Over carton	17,9*16,5*9,45	455*420*240

Benefits

Most powerful tool on the market in its class: 922 ft.lbs / 1250 Nm of maximum real torque in reverse

Best price to performance/durability ratio

Lightweight due to composite housing

Contoured comfort grip handle instead of TPR injected in handle

Smooth Forward / Reverse Switch on back

Suited for all maintenance applications: Light vehicle tire changing, General maintenance on vehicles and MRO applications

Features

1/2" composite impact wrench

One handed forward/reverse

Full power in reverse: 922 ft. lb - 1250 Nm maximum real torque in reverse

3 positions in forward: Low - 180 ft-lbs. / 245 Nm - Medium - 480 ft-lbs. / 650 Nm - High - 730 ft-lbs. / 990 Nm

Aluminum clutch and back housing

Friction ring socket retainer

Full teasing trigger

Curved to be more ergonomic, Smaller diameter to fit better in hand palm and to be optimum balanced

Handle with Thermo-Plastic Rubber injected in housing for a durable and comfortable grip; Resistant to most chemicals used in workshops

Twin hammer mechanism

360degree swivel air inlet

Composite housing

For more information on the CP7748 impact wrench please call Zampini Industrial Group at 1-800-353-4676 and we will be happy to assist you.
