Description
Part number | 8941077820 | |
Model | CP7782 | |
Handle type | D-Handle Inside Trigger | |
Square drive | 1" | |
Working Torque Range (fwd) | 370 - 1475 ft.lbs | 500 - 2000 |
Maximum Torque (reverse) | 1920 ft.lbs | 2600 Nm |
Free speed | 5200 rpm | |
Blows per minute | 500 | |
Net weight | 22.2 lb | 10.1 kg |
Power/weight ratio | 86.5 ft.lb/lb | 257.4 Nm/kg |
Length | 14.7" | 370 mm |
Average air consumption | 10 cfm | |
Actual air consumption | 40.7 cfm | |
Air inlet thread size | 0.5 " | |
Min. hose size | 1/2" | 13 mm |
Noise level | 100 db(A) | |
Sound Power | 111 db(A) | |
Vibration α (ISO-28927-2) | 7.8 m/s² | |
Vibration K (ISO-28927-2) | 1.8 m/s² | |
Socket retainer | Dual (hole+friction) | |
Clutch type | Pin less closed rocking dog | |
Box dimensions | 26,35*9,6*5,11 | 670*245*130 |
Over carton | 26,35*9,6*5,11 | 670*245*130 |
Benefits
Features
For more information on the CP7782 impact wrench please call Zampini Industrial Group at 1-800-353-4676 and we will be happy to assist you.
