Description
Exhaust is through common exhaust port and opposite rotation inlet port. Blocking or restricting these ports will reduce the performance of the motor. Air motors are supplied as 'Machinery to be incorpoarted' - Customer is responsible for safe incorporation into complete machine. Always refer to Operating and Warning instructions supplied with the tool before operating the tool. * Tools marked ' Torque motor capability' can be transformed into torque motors with the addition of torque control units.
View AllClose
| Part Number | Description | Free Speed | Max. Power | Torque at Max. Power | Length | Comment |
| rpm | hp | in lb | in | |||
| 1309944 | 2HM5-18000 | 18000 | 0.87 | 5.8 | 7.42 | |
| 1309864 | 2HM5-3300 | 3300 | 0.87 | 33.6 | 7.42 | |
| 1309784 | 2HM5-2100 | 2100 | 0.87 | 49.6 | 7.42 | |
| 1309604 | 2HM5-950 | 950 | 0.87 | 115.1 | 9.13 | * Torque motor capability |
| 1309524 | 2HM5-550 | 550 | 0.87 | 185.9 | 9.13 | * Torque motor capability |
| 1309444 | 2HM5-350 | 350 | 0.87 | 278.8 | 9.13 | * Torque motor capability |
| 1309284 | 2HM5-150 | 150 | 0.87 | 362.9 | 10.61 | * Torque motor capability |
| 1309104 | 2HM5-100 | 100 | 0.87 | 362.9 | 10.61 | |
| 1309024 | 2HM5-40 | 40 | 0.87 | 362.9 | 1061 |
Desoutter Industrial Tools are some of the finest tools available for production and manufacturing tool applications. AirToolPro.com by Zampini Industrial Group is a premier distributor of Desoutter Air and Electric Tools, and has been a trusted Desoutter Partner since 1987! From precision torque screwdrivers to DC Electric systems to proven high performance air grinders, Desoutter has you covered. Desoutter tools have best in class performance, fit, and finish, and they are designed to achieve the impressive goals below as thoroughly as possible:
| - Good Balance | - Minimize Vibration |
| - Low Weight | - Minimize Exhaust Air Jet |
| - Minimize Torque Reaction | - Maximize Power To Weight Ratio |
| - Thermal Insulation | - Minimize Oil From Exhaust |
| - Minimize Torque Impulse | - Appropriate Size |
| - Minimize Necessary Trigger Loading | - Excellent Grip |
