Desoutter CP0214FAREL-5 Compression Rivet Squeezer


Please Call For Pricing and Availability
Please Call For Pricing and Availability


Desoutter CP0214FAREL-5 Compression Rivet Squeezer

Part number6151710150
Capacity aluminum3/16"4.8 mm
Capacity aluminum4.8 mm3/16"
Capacity steel0.15625"4 mm
Capacity steel4 mm0.15625"
Std yoke dimensions reach1.969"50 mm
Std yoke dimensions reach50 mm1.969"
Std yoke dimensions closed height0,669/0,78717/20
Std yoke dimensions closed height17/20 0,669/0,787
Max force (90 psi/ 6.2bar)6000 lb
Max force (90 psi/ 6.2bar)26.7 kN
Moving plunger max. travel9/16"14.3 mm
Moving plunger max. travel14.3 mm9/16"
Moving plunger final part of stroke at max. force0.063"1.6 mm
Moving plunger final part of stroke at max. force1.6 mm0.063"
Cylinder typeTandem
Rivet set type5mm
Net weight5 1/2 lb2 1/2 kg
Net weight2.5 kg5 1/2 lb
Length14"356 mm
Length356 mm14"
Sound pressure90 db(A)
Sound Power101 db(A)
Vibration (ISO-28927-4)<2.5 m/s²


  • Tandem Cylinder

  • Desoutter Air and Electric Industrial Tools Banner

    Desoutter Industrial Tools are some of the finest tools available for production and manufacturing tool applications. by Zampini Industrial Group is a premier distributor of Desoutter Air and Electric Tools, and has been a trusted Desoutter Partner since 1987! From precision torque screwdrivers to DC Electric systems to proven high performance air grinders, Desoutter has you covered. Desoutter tools have best in class performance, fit, and finish, and they are designed to achieve the impressive goals below as thoroughly as possible:

    - Good Balance - Minimize Vibration
    - Low Weight - Minimize Exhaust Air Jet
    - Minimize Torque Reaction - Maximize Power To Weight Ratio
    - Thermal Insulation - Minimize Oil From Exhaust
    - Minimize Torque Impulse - Appropriate Size
    - Minimize Necessary Trigger Loading - Excellent Grip
