Desoutter 2H16-L-250-800 Lever start Button reverseB18 output Tapper

Write a Review
Please Call For Pricing and Availability
  • Desoutter 2H16-L-250-800 Lever start Button reverseB18 output Tapper


Part number1434184
High speed setting800 rpm
Low speed setting250 rpm
Max. tapping torque90 Nm66.4 ft.lbs
Max. tapping torque66.4 ft.lbs90 Nm
Max. tapping torque low speed90 Nm66.4 ft.lbs
Max. tapping torque low speed66.4 ft.lbs90 Nm
Max. tapping torque high speed29 Nm21.4 ft.lbs
Max. tapping torque high speed21.4 ft.lbs29 Nm
Output spindle tapperB18
Type of toolStand mounted
OperationButton reverse
Net weight3.1 kg6.8 lb
Net weight6.8 lb3.1 kg
Length332 mm13.07"
Length13.07"332 mm
Actual air consumption15.6 l/s33.1 cfm
Actual air consumption33.1 cfm
Air inlet thread size1/4 "
Air inlet thread size0.25 BSP
Min. hose size12 mm1/2"
Min. hose size1/2"12 mm
Noise level76 db(A)
Vibration (ISO-8662-6)<2.5 m/s²
