Description
| Model | 15TE20-P |
| Tank (gal) | 120 horizontal |
| Max Pressure (psig) | 175 |
| Nominal Power (hp) | 20 |
| Flow at Max Pressure (cfm) | 72.0 |
| Base Length (in) | 88 |
| Base Width (in) | 46 |
| Base Height (in) | 65 |
| Weight (lbs) | 1597 |
| NPT Outlet (in) | 3/4 |
| Voltage/Engine | 200, 230, 460 - 3 - 60 |
- Durable cast iron design for 100% continuous duty application
- Precision engineered components for high reliability
- Individually cast cylinders, overhung crankshaft and one piece connecting rod for ease of maintenance and service
- High efficiency finger valves
- 175 psig maximum operating pressure for applications requiring high air capacity and pressure
- Extended 2 year warranty when used with Ingersoll Rand
