Model | 2-2475E5-P |
Tank (gal) | 120 horizontal |
Max Pressure (psig) | 175 |
Nominal Power (hp) | 5 |
Flow at Max Pressure (cfm) | 34.2 |
Base Length (in) | 84 |
Base Width (in) | 35 |
Base Height (in) | 48 |
Weight (lbs) | 1265 |
NPT Outlet (in) | 0.5 |
Voltage/Engine | 200, 230, 460, 575 - 3 - 60 |
- Durable cast iron design for 100% continuous duty application
- Automatic duplexing or alternating of compressors depending on compressed air requirements
- Individually cast cylinders, overhung crankshaft and one piece connecting road for ease of maintenance and service
- 175 psig maximum operating pressure for applications requiring high air capacity and pressure
- Extended 2 year warranty when used with Ingersoll Rand All Season Select synthetic lubricant
Ingersoll Rand duplex reciprocating air compressors offer two individual compressor pumps and two motors mounted on a single tank, providing 100% built-in backup or additional air power for those larger capacity jobs. The Duplex is ideal in applications where available power does not allow for a single larger compressor. The latest generation of Ingersoll Rand duplex reciprocating compressors has the legendary Type 30 pump with value added features in a space saving design suitable for those tight spaces. The duplex packages are available in Value and Premium configurations with factory fitted options ready-to-use.
