Description
| Model | 2-7VE5 |
| Tank (gal) | 120 horizontal |
| Max Vacuum (inHg) | 29 |
| Nominal Power (hp) | 5 |
| Piston Displacement (cfm) | 198 |
| Length (in.) | 74 |
| Width (in) | 54 |
| Height (in) | 59 |
| Weight (lbs) | 2100 |
| NPT Outlet (in) | 2 |
| Voltage/Engine | 115, 230 - 1- 60 / 200, 230, 460, 575 - 3 - 60 |
- 100% cast iron frame and cylinders for durability and long life
- Separately cast cylinders with deep fins for improved cooling and efficiency
- Low oil level switch standard on all packages to prevent compressor from potential damages due to low oil level
- Easily accessible stainless steel valve and one piece connecting rod improves serviceability and reduces cost of maintenance
- Maximum vacuum of 29
