Description
Model | 2475N7.5-V |
Tank (gal) | 80 vertical |
Max Pressure (psig) | 175 |
Nominal Power (hp) | 7.5 |
Flow at Max Pressure (cfm) | 24.0 |
Base Length (in) | 48 |
Base Width (in) | 40 |
Base Height (in) | 76 |
Weight (lbs) | 611 |
NPT Outlet (in) | 3/4 |
Voltage/Engine | 230 - 1- 60 / 200, 230, 460, 575 - 3 - 60 |
- Durable cast iron design for 100% continuous duty application
- Precision engineered components for high reliability
- Individually cast cylinders, overhung crankshaft and one piece connecting rod for ease of maintenance and service
- High efficiency finger valves
- 175 psig maximum operating pressure for applications requiring high air capacity and pressure
- Extended 2 year warranty when used with Ingersoll Rand
