Chicago Pneumatic CP7748 1/2" Impact Wrench | 922 Ft. Lbs. | DISCONTINUED ITEM

CP7748 - Durable, Powerful & Ergonomic

Benefits

Most powerful tool on the market in its class: 922 ft.lbs €“ 1250 Nm of maximum real torque in reverse

Best price to performance/durability ratio

Lightweight due to composite housing

Contoured comfort grip handle instead of TPR injected in handle

Smooth Forward / Reverse Switch on back

Suited for all maintenance applications: Light vehicle tire changing, General maintenance on vehicles and MRO applications

Features

1/2" composite impact wrench

One handed forward/reverse

Full power in reverse: 922 ft. lb - 1250 Nm maximum real torque in reverse

3 positions in forward: Low - 180 ft-lbs. / 245 Nm - Medium - 480 ft-lbs. / 650 Nm - High - 730 ft-lbs. / 990 Nm

Aluminum clutch & back housing

Friction ring socket retainer

Full teasing trigger

Curved to be more ergonomic, Smaller diameter to fit better in hand palm and to be optimum balanced

Handle with Thermo-Plastic Rubber injected in housing for a durable and comfortable grip; Resistant to most chemicals used in workshops

Twin hammer mechanism

360° swivel air inlet

Composite housing

Available now at AirToolPro / Zampini Industrial 1-800-353-4676

Part number	8941077480
Model	CP7748
Over carton	455*420*240	17,9*16,5*9,45
Over carton	17,9*16,5*9,45	455*420*240
Handle type	Pistol
Square drive	1/2"
Working Torque Range (fwd)	102-786 Nm	75-580
Working Torque Range (fwd)	75-580 ft.lbs	102-786
Maximum Torque (reverse)	1250 Nm	922 ft.lbs
Maximum Torque (reverse)	922 ft.lbs	1250 Nm
Free speed	8200 rpm
Blows per minute	1200
Net weight	4.6 lb	2 kg
Net weight	2 kg	4.6 lb
Power/weight ratio	625 Nm/kg	200.434782608696 ft.lb/lb
Power/weight ratio	200.434782608696 ft.lb/lb	625 Nm/kg
Length	7.8"	200 mm
Length	200 mm	7.8"
Side to center	38 mm	1,50"
Side to center	1,50	38
Average air consumption	6.2 cfm
Average air consumption	3 l/s	6.2 cfm
Actual air consumption	25 cfm
Actual air consumption	12 l/s	25 cfm
Air inlet thread size	0.25 "
Min. hose size	10 mm	3/8"
Min. hose size	3/8"	10 mm
Noise level	93 dBa
Sound Power	104 dBa
Vibration α (ISO-28927-2)	10.1 m/s²
Vibration K (ISO-28927-2)	2.34 m/s²
Socket retainer	Friction ring
Clutch type	Twin Hammer
Box dimensions	215*210*77	8,5*8,25*3,03
Box dimensions	8,5*8,25*3,03	215*210*77
