Description
|
| Part number | T025379 | |
| Model | CP897 | |
| Out of production | Out of production | |
| Handle type | Straight | |
| Square drive | 1" | |
| Working Torque Range (fwd) | 150-800 ft.lbs | 203-1085 |
| Maximum Torque (reverse) | 1300 ft.lbs | 1763 Nm |
| Free speed | 3800 rpm | |
| Blows per minute | 720 | |
| Weight | 16.25 lb | 7.37 kg |
| Length | 13.75" | 349 mm |
| Average air consumption | 6.5 cfm | |
| Actual air consumption | 26 cfm | |
| Air inlet thread size | 1/2 in. | |
| Min. hose size | 1/2" | 13 mm |
| Noise level | 101 db(A) | |
| Sound Power | 112 db(A) | |
| Vibration (ISO-8662-7) | 7.5 m/s² | |
| Vibration α (ISO-28927-2) | 12.1 m/s² | |
| Vibration K (ISO-28927-2) | 4.1 m/s² | |
| Socket retainer | Friction ring  Click to enlarge | |
| Clutch type | Pinless rocking dog  Click to enlarge | |
