Description
|
Part number | T025379 | |
Model | CP897 | |
Out of production | Out of production | |
Handle type | Straight | |
Square drive | 1" | |
Working Torque Range (fwd) | 150-800 ft.lbs | 203-1085 |
Maximum Torque (reverse) | 1300 ft.lbs | 1763 Nm |
Free speed | 3800 rpm | |
Blows per minute | 720 | |
Weight | 16.25 lb | 7.37 kg |
Length | 13.75" | 349 mm |
Average air consumption | 6.5 cfm | |
Actual air consumption | 26 cfm | |
Air inlet thread size | 1/2 in. | |
Min. hose size | 1/2" | 13 mm |
Noise level | 101 db(A) | |
Sound Power | 112 db(A) | |
Vibration (ISO-8662-7) | 7.5 m/s² | |
Vibration α (ISO-28927-2) | 12.1 m/s² | |
Vibration K (ISO-28927-2) | 4.1 m/s² | |
Socket retainer | Friction ring Click to enlarge | |
Clutch type | Pinless rocking dog Click to enlarge |
