Description
- Jumbo hammer mechanism
- 1,200 ft-lb of maximum torque
- Pressure-fed lube system for trouble-free performance and longer life
| Model | 261-6 |
| Nut Busting Torque ft-lb (Nm) | |
| Max. Torque in Reverse ft-lb (Nm) | 1,200 (1627) |
| Working Torque Range ft-lb (Nm) | 200-900 (272-1224) |
| Forward Torque Range ft-lb (Nm) | |
| Weight lb (kg) | 13.7 (6.21) |
| Free Speed rpm | 5,500 |
| Impacts per minute | 1,000 |
| Length in (mm) | 14.8 (376) |
| Average Air Consumption cfm (L/min) | 9.5 (269) |
| Air Consumption @ Load cfm (L/min) | 38 (1076) |
| Sound Pressure/Power dBA | 98.1/109.1 |
| Air Inlet NPTF in (mm) | 3/8 (10) |
| Min. Hose Size in (mm) | 1/2 (13) |
The highly-regarded 261 model combines compact size at only 8.8" long with high output, which makes it perfect for everything from spring work to pinion nut and track pad removal and major engine teardowns.
CCN Number 1217199
