Description
| Model | 77A25F107 |
| Rated Power hp (kW) | 1.5 (1.12) |
| Max Free Speed (rpm) | 2,500 |
| Exhaust | Side |
| Output | 5/8" - 11 Thread, 7" Polishing Bonnet |
| Wheel Size in. (mm) | 7" (180) |
| Weight lbs. (kg) | 8.38 (3.7) |
| Length in. (mm) | 17.56" (446) |
| Vibration m/s2 | < 2.5 |
| Sound Pressure/Power dBA | 92.2 / 105.2 |
| Average Air Consumption cfm (L/min) | |
| Air Consumption @ Load cfm (L/min) | 37 (1048) |
| Air Inlet Size NPT in. | 3/8" |
| Min Hose Size in. (mm) | 1/2" (13) |
Pro Series Sanders are designed for applications involving larger areas and heavier-duty materials, Pro Series sanders range from 0.80 - 3.0 hp (0.60 - 2.24 kW) . They incorporate many of the same unique features as their counterpart grinder models.
- 61 = Series (61, 77, 88, 99)
H = Type (A- angle, H- horizontal, V- vertical)
30 = Free Speed RPM (x 100)
B = Type of Wheel (B- wire brush, F- polishing head, W- sanding head)
10 = Arbor Diameter (10- 5/8"-11 Thread)
6 = Wheel Diameter in. (6, 7, 8, 9) - Solid steel motor and arbor housing provide maximum durability
- Built-in mist lubricator automatically oils motor when throttle is activated
- Heavy-duty, double-row ball bearings assure long life and smooth operation
