| Model | IRN10H-100 |
| Frequency (Hz) | 60 |
| Rated Pressure (barg / psig) | 8 / 115 |
| Nominal Power (kW / hp) | 7.5 / 10 |
| Flow (m3min / cfm) | 1.19 / 42 |
| Length (cm / in) | 131 / 52 |
| Width (cm / in) | 84 / 33 |
| Height (cm / in) | 73 / 29 |
| Weight (kg / lbs) | 350 / 780 |
- Maximum operating flexibility to meet your individual site needs
- Total Air System in one package
- World class sound as low as 65 dB(A)
- High quality filtered and dried discharge air
- Lowest power consumption at start-up, full load, and part load conditions
- Up to 35% energy savings
- Inherent reliability through elimination of wear parts and simplicity of design
Continuing with the Ingersoll Rand Nirvana product tradition, the 5.5-30 kW (7.5-40 hp) variable speed rotary screw compressor embodies advancements in aligning technology and reliability. Nirvana provides the ability to match compressed air demand while ensuring the lowest power consumption and operating cost. The Total Air System (TAS) option provides one integrated solution for all the required components of a complete compressed air system and offers superior air quality, world class noise levels and no hassle installation. Further, Nirvana
