Description
The QE8A Series of angle wrenches when teamed with the IC Series DC Electric Tool Controllers provide superior accuracy and durability to meet your fastening requirements. The QE8A offer a torque range from 13 Nm to 400 Nm with speeds up to 1200 RPM. Bright LEDs and TactAlert provide positive feed back to the operators without distracting them from their task. The non-contacting switches, heavy duty gear train and DC brushless motor create a durable package that will keep your maintenance cost down. The small size, high speed, ergonomic grip and easy accessible controls will help keep your production line running smoothly.
Tool
- High free speed
- Compact lightweight design
- High duty cycle
- Status lights
- Status lights
- Non-contacting switches
- Trigger or lever start
- Rotary reverse switch
Cables
- Durable flexible cables
- 3, 6, and 10 meter tool cable lengths ..... Straight or 90 degree versions
- 10, 20 and 40 meter extensions cables
Accessories
- Socket trays
- Selector switches
- ICS Software
- Suspension bails
- Torque arms and tubes
Productivity
- Faster speeds at torque than competitive tools
- Automatic tool identification means any Insight controller can instantly recognize any QE tool — without manual entry of tool torque range, motor charcteristics, or transducer values
- Improved accuracy with Sine Drive technology
- Programmable momentary switch
- Optimum flexibility through modular designs
- Patented TactAlert provides the operator with tactile feedback of a tool fault or NOK signal through gentle mechanical oscillation in the grip surface, reducing reliance on visual or audible signals
Ergonomics
- Compact, lightweight designs
- Comfortable grip surfaces and smooth contours
- Low-force triggers and rotary reverse switches
Reliability
- Digital link between tool and controller
- Durable chassis
- Non-contacting switches
- Two-year standard warranty on all tool cables
Model | CPN | Free Speed rpm | Max Torque Nm | Spindle Size in | Torque Range Nm |
QE8AT065PA5S08 | 16676983 | 1200 | 65 | 1/2 | 13.0-52.0 |
QE8AT065PA6S08 | 10567592 | 1200 | 65 | 1/2 | 13.0-52.0 |
QE8AT070PA5S08 | 16676991 | 1100 | 70 | 1/2 | 14.0-56.0 |
QE8AT070PA6S08 | 10567618 | 1100 | 70 | 1/2 | 14.0-56.0 |
QE8AT090PA5S08 | 16675662 | 850 | 90 | 1/2 | 18.0-72.0 |
QE8AT090PA6S08 | 10567634 | 850 | 90 | 1/2 | 18.0-72.0 |
QE8AT115PA6S08 | 15969975 | 660 | 115 | 1/2 | 23.0-92.0 |
QE8AT150PA6S08 | 16675779 | 510 | 150 | 1/2 | 30.0-120.0 |
QE8AT225PA7S12 | 16679086 | 310 | 225 | 3/4 | 45.0-180.0 |
QE8AT400FA8S12 | 16679094 | 170 | 400 | 3/4 | 80.0-320.0 |
