Description
| Model | 8509-APR-A |
| Torque Range Soft Draw Nm | .9-5.7 |
| Free Speed rpm | 900 |
| Spindle Offset in. | .9 |
| Air Consp. @ Free Speed L/s | 12.2 |
| Tool Length mm | 226 |
| Sound Level dB(A) @ Free Speed | 82 |
| Torque Range Soft Draw in.-lbs | 8-50 |
| Weight lb | 3.1 |
| Tool Weight kg | 1.4 |
| Spindle Offset mm | 23 |
| Air Consp. @ Free Speed cfm | 26 |
| Length in. | 8.9 |
Torque Output: 8-70 in.-lbs ( 0.9 to 7.9 Nm ) Quick Reverse Trigger - Adjustable Cushion Clutch
- Recommended for assembling that requires a torque limiting clutch.
For more information on the Ingersoll Rand 8509-APR-A please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4163002
