Description
| Model | 41PP25TSQ4 |
| Torque (Soft Draw) 90 psi Nm | 5.1 |
| Free Speed rpm | 2500 |
| cfm | 20 |
| Torque (Soft Draw) 50 psi in.-lb. | 25 |
| Torque (Soft Draw) 50 psi Nm | 2.8 |
| Side to Center Distance in. | .80 |
| Weight lb | 2.30 |
| Length in. | 7.20 |
| Torque (Soft Draw) 90 psi in.-lb. | 45 |
| Weight, (kg) | |
| Side to Center (mm) | |
| Length (mm) | |
| Torque (soft draw) (Nm) | |
| Screw Size Range | |
| Air Consumption (L/min) | |
| Bit Holder Capacity (in) |
Torque Output: 45 to 120 in.-lbs ( 4 to 13.6 Nm ) Positive Clutch
- Recommended for assembling that requires more driving torque than final seating torque.
For more information on the Ingersoll Rand 41PP25TSQ4 please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4247045
