Description
| Model | SG022B-15-Q |
| Stall Torque (in.-lbs) | 25 |
| Free Speed rpm | 1500 |
| Spindle Offset in. | .66 |
| Stall Torque Nm | 2.8 |
| Air Consp. @ Free Speed L/s | 7 |
| Tool Length mm | 140 |
| Sound Level dB(A) @ Free Speed | 76 |
| Jaw | Angle Jaws |
| Weight lb | 1.6 |
| Tool Weight kg | .7 |
| Spindle Offset mm | 17 |
| Air Consp. @ Free Speed cfm | 15 |
| Length in. | 5.5 |
Torque Output: 12 to 38 in.-lbs ( 1.4 to 4.3 Nm ) Positive Clutch
- Recommended for assembling that requires more driving torque than final seating torque.
For more information on the Ingersoll Rand SG022B-15-Q please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4049391
