Description
Model | SQ024C-8-Q |
Free Speed rpm | 800 |
Spindle Offset in. | .75 |
Torque Range-Soft Draw In.-lbs | 4-40 |
Type | Trigger Permit |
Air Consp. @ Free Speed L/s | 7 |
Tool Length mm | 191 |
Sound Level dB(A) @ Free Speed | 79 |
Weight lb | 2.0 |
Tool Weight kg | .9 |
Spindle Offset mm | 19 |
Air Consp. @ Free Speed cfm | 15 |
Length in. | 7.5 |
Torque Range-Soft Draw Nm | .50-4.5 |
Torque Output: 3 to 40 in.-lbs ( .34 to 4.5 Nm ) Quick Reverse Trigger - Automatic Shut-off Clutch
- Recommended for assembling where precise torque control is required.
For more information on the Ingersoll Rand SQ024C-8-Q please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4181814
