Description
Convenient and innovative Quick Reverse Trigger and Automatic Shut-off Clutch
Model | SQ024C-15-Q |
Free Speed rpm | 1500 |
Spindle Offset in. | 0.75 |
Torque Range-Soft Draw In.-lbs | 3.0-20.36 |
Type | Trigger Permit |
Air Consp. @ Free Speed L/s | 7 |
Tool Length mm | 191 |
Sound Level dB(A) @ Free Speed | 79 |
Weight lb | 2 |
Tool Weight kg | 0.9 |
Spindle Offset mm | 19 |
Air Consp. @ Free Speed cfm | 15 |
Length in. | 7.5 |
Torque Range-Soft Draw Nm | .34-2.3 |
Features
- Recommended for assembling where precise torque control is required
The most accurate of all air screwdrivers, adjustable shut-off (or automatic shut-off) screwdrivers are designed for critical fastening applications involving plastics, composites, or metals that require precise torque control. The final fastening torque is set by adjusting the compression of a clutch spring within the front section of the tool. This class of tools is recommended for hard or soft joints or for self-tapping or sheet metal screws provided tapping torque does not exceed the final torque. Automatic shut-off tools also reduce air consumption and are the most ergonomically sound of all air screwdrivers.
