Description
| Part number | 2051479764 | |
| Model | M180-145-K-ATEX | |
| Max. Output Power | 2.41 hp | |
| TorqueAtMaxPower_ftlbs | 167 ft.lbs | 227 Nm |
| Mini starting torque | 249 ft.lbs | 337 Nm |
| Stall torque | 335 ft.lbs | 454 Nm |
| Free speed | 145 rpm | |
| ATEX | YES | |
| ATEX Directive | II 2GD c T6 IIC T85C | |
| Reversible | NO | |
| Back head coaxial | NO | |
| Front nut threaded | NO | |
| Lubrication free | NO | |
| Stainless steel | NO | |
| Net weight | 11.1 lb | 5.1 kg |
| Air flow at max. capacity | 72 cfm | |
Benefits
Features
For more information on the M180-145-K-ATEX air motor, please call us at 1-800-353-4676 today.
Air motors are an ideal solution for many applications in such varied equipment as material handling, packaging, strapping, or printing machinery, petrochemical and agricultural equipment, food processing machinery, and many more custom and standard machines. Air motors offer many advantages over electric motors, and are often the only feasible option for driving automation.
To view our complete selection of pneumatic air motors, return to Air Motors - Home.
