CP7780-6 Air Impact Wrench | 1" | 1550 ft.lbs | 8941077806  | by Chicago Pneumatic

CP7780-6 - Lightweight & powerful

Part number	8941077806
Model	CP7780-6
Handle type	D-Handle Inside Trigger
Square drive	1"
Working Torque Range (fwd)	350-1650 Nm	260-1220
Working Torque Range (fwd)	260-1220 ft.lbs	350-1650
Maximum Torque (reverse)	2100 Nm	1550 ft.lbs
Maximum Torque (reverse)	1550 ft.lbs	2100 Nm
Free speed	5000 rpm
Blows per minute	790
Net weight	17 lb	7.7 kg
Net weight	7.7 kg	17 lb
Power/weight ratio	272.7 Nm/kg	91.2 ft.lb/lb
Power/weight ratio	91.2 ft.lb/lb	272.7 Nm/kg
Length	19.3"	490 mm
Length	490 mm	19.3"
Average air consumption	12 cfm
Average air consumption	5.6 l/s	12 cfm
Actual air consumption	49.8 cfm
Actual air consumption	23.4 l/s	49.8 cfm
Air inlet thread size	0.5 "
Min. hose size	13 mm	1/2"
Min. hose size	1/2"	13 mm
Noise level	94 db(A)
Sound Power	105 db(A)
Vibration α (ISO-28927-2)	13.9 m/s²
Vibration K (ISO-28927-2)	3.4 m/s²
Socket retainer	Dual (hole+friction)
Clutch type	Twin hammer oil bath
Box dimensions	512*198*136	20.2*7.8*5.4
Box dimensions	20.2*7.8*5.4	512*198*136
Over carton	527*212*291	20.7*8.3*11.5
Over carton	20.7*8.3*11.5	527*212*291

Benefits

Maximize operator comfort with a lightweight impact

Ergonomic and intuitive handling

High Power to Weight ratio for General Maintenance applications

Features

1" straight impact wrench with 6" extended anvil

17 lbs (7,7 kg) thanks to an aluminum housing giving less fatigue to the operator

1550 ft.lbs (2100Nm) maximum torque in reverse

Integrated protective cover on the clutch housing

Twin hammer mechanism in oil bath

Dedicated lever for forward and reverse

Ergonomic side handle with soft touch grip

4-positions power setting for both directions and on both sides of the tool

Socket retainer ring combined with hole retainer

For more information on the CP7780-6 impact wrench please call Zampini Industrial Group at 1-800-353-4676 and we will be happy to assist you.

Established in 1901, Chicago Pneumatic Tools offers hundreds of quality air tools designed for a wide range of maintenance and production applications: impact wrenches, ratchet wrenches, screwdrivers, drills, grinders, sanders and polishers, cutting tools, and a whole lot more. Based on decades of expertise in providing the right tools, compressors or construction equipment for the toughest demands, CP understand the needs of the professionals for maintaining and repairing heavy equipment and machinery on-site or off-site.

Zampini Industrial Group is proud to be a premier online supplier of Chicago Pneumatic Tools, and our numerous years representing the CP brand has provided us with a wide range of valuable application experiences that we use to help you get the perfect CP tool for your job!
