Description
Setting or checking the torque applied in a joint
The CD, CF and TD type torque transducers are used to check and correct torque on already tightened joints by breakaway measurement on re-tightening.
They also allow you to perform the tightening operation itself while monitoring the progress of the torque value. The active component is a bending test bar to which the strain gauges are glued.
CD series: Torsion static torque wrenches from 1 to 1500Nm.
Setting pneumatic nutrunners, torque-limiting wrenches, etc.
Model Number |
| CD4001 |
Part no |
| 6151651460 |
Description |
| CD4001 |
Square drive | in | 3/8in |
Torque range | ft.lb | 0.7-11 |
Sensitivity | Mv/v | 1.475 |
Sensitivity | ft.lb | 7.4 |
Linearity uncertainty | ft.lb | 0.01 |
Length | in | 11.1 |
Weight | lb | 1.3 |
