Description
TD series: The screwdriver is fitted with a spirally wound cord (extended length 1.5m - 59') for connection to a torque measuring unit. It is supplied in a case specially designed for screwdriver bits.
Setting or checking the torque applied in a joint
The CD, CF and TD type torque transducers are used to check and correct torque on already tightened joints by breakaway measurement on re-tightening.
They also allow you to perform the tightening operation itself while monitoring the progress of the torque value. The active component is a bending test bar to which the strain gauges are glued.
Model Number |
| TD2001 |
Part no |
| 6151651530 |
Description |
| TD2001 |
Square drive | in | Hex 1/4in |
Torque range | ft.lb | 0.7-11 |
Sensitivity | Mv/v | 1.475 |
Sensitivity | ft.lb | 7.4 |
Linearity uncertainty | ft.lb | 0.01 |
Length | in | 8.1 |
Weight | lb | 0.8 |
