Toman 2010 & 2010T Manual Lever Operated Thermal Assembly Heat Stakers

These lever-arm, bench-top systems are ideal for single point or small, multi-point assembly operations. Each unit is exceptional for short run prototype work and for testing new applications. The 2010T has a built-in timer and signal light. The operator can set and adjust the cycle time, insuring that each part is assembled for the same amount of time. This improves part-to-part consistency and reliability. No lab or molding house should be without one or both of these units.

Features:

• Cast aluminum base with fixture-mounting bolt hole pattern
• Adjustable, locking depth stop for accurate tool adjustment
• Microprocessor based, digital display, temperature controller with digital set point and process value readout
• Thermal probe with built-in thermocouple
• 80-999 degree F. operating range +/-2 degree accuracy
• Non-asbestos insulator
• Easy-access on/off switch

Additional Features for the 2010T:

• 1-10 second, adjustable assembly timer
• Cycle complete light
• Magnetic switch that starts timer (not shown)

SPECIFICATIONS
Power requirements: 110 VAC, 50/60 Hz
Current draw @ full rated output: 2.5 amps
Stroke length: 2.5" (6.3 cm)
Weight: 34 lbs

CUSTOM OPTIONS (Quoted Upon Request)
Extended column height
Extended throat depth
Post cooling system
3" x 3" multi-point platen



BY004 - 2010 Unit with Probe

BY007 - 2010T Unit with Probe & Timer
