2020 VISION Series Smart Pneumatic Thermal Assembly System

These heat staking systems are advanced STATE-OF-THE-ART “SMART” Systems. The brain of these intelligent systems is an Embedded Microprocessor. This pneumatically-operated bench-top system’s Standard “Smart” Features Include: 3–Post/In-Cycle Cool modes; 2 Parts Counters; 1 resetable and 1 lifetime; Program Memory for up to 5-different setup parameters and Maintenance Screen. The systems Plug and Play intelligence allows for Instant change of machine operation between: Basic Machine Operation and Optional Slide Table and Our Standard 2 position Rotary Table. The Maintenance Screen allows for easy troubleshooting of system operation. This feature shows the status of the inputs and outputs of the Embedded Microprocessor. The adjustable Head Height includes a pair of column clamp handles and a counter balance spring, which make the head both light and easy to move.

Additional Features for the 2020 & 2020HD

• 120 pounds of down force
• Head table Head height, from 4” to 16”
• Adjustable mechanical stop for fine tool adjustment
• Digital dwell timers for repeatable process control for both the heat cycle and cool cycle
• Adjustable Hydraulic Decelerator for controlled
  tooling advance
• Dual, anti-tie-down, no-touch ergonomic actuation
• 80-999 degree F operating range +/- 2 degree accuracy
• Microprocessor-based, digital display temperature controller for accurate thermal process control
• Standard Thermal Probe has built-in thermocouple
• Non-asbestos insulator
• 3” x 4” upper tooling platen
• Cast Aluminum Base with E-Stop and fixture
  mounting holes
• Air filter regulator and air flow controls to adjust up and down stroke speeds


Additional Features for the 2020HD only

• 1/4 ton of down force
• Heavy duty press allows for multiple staking or insertion

SPECIFICATIONS
Power Requirements 110VAC, 50/60 Hz
Current draw @ full rated output: 5 amps
Pneumatic requirements Clean, dry air @ 100 psig
Maximum force (2020) 120 lbs. @ 100 psig
(2020HD) 500 lbs. @ 100 psig
Stroke Length 4” (10.16 cm)
Head adjustment 4’ to 16”
Weight 72 lbs.

BY126 - 2020 Vision Unit with Probe

BY127 - 2020HD Vision Unit with Probe
