2030MZ (Multi-Zone)
THERMAL ASSEMBLY SYSTEM

This versatile, bench top system also develops 1/2 ton of down force and is ideal for assembling components within a 12"x18" area. It can work on multiple planes or in restricted areas during a single cycle. The unit is standard with two zones but can accomodate up to six zones that are individually monitored by a microprocessor-based, digital display, temperature controller. It comes with a convenient screw and nut arrangement for coarse head height adjustments.

 Tools of different lengths, and for different tasks, can be combined on the same tooling platen. Multiple parts can be fixtured for simultaneous processing. One 2030MZ can often solve production problems that would otherwise require expensive, multiple assembly systems. In addition, the unit is easily adaptable for integration into rotary or in-line automated assembly systems.

Features:

• Head height adjustment from 7 1/2" - 19 1/2"
• Adjustable mechanical stop for accurate tool adjustment
• Head-down, setup switch
• Dual ram speed for decreased cycle time
• Digital readout, dwell timer for repeatable process control
• A microprocessor-based, digital display controller for accurate temperature regulation of each zone
• 6" x 6" platen for upper tooling
• 80-999 degree F. operating range +/-2 degree accuracy
• Dual anti-tiedown, no-touch ergonomic actuation
• Separate, heater on/off switch
• Adjustable shock absorber for controlling tooling advance
• Emergency stop; non-asbestos insulator; flow controls for adjustable stroke speeds; air filter regulator; base with fixture mounting holes

SPECIFICATIONS
Power requirements: 110 VAC, 50/60 Hz
Current draw @ full rated output: 10 amps
Pneumatic requirements: Clean, dry air @ 100 psig
Maximum Force: 1,200 lbs @ 100 psig
Stroke length: 4" (10.16 cm)
Weight: 350 lbs

CUSTOM OPTIONS
(Quoted Upon Request)
Manual or Pneumatic Slide Table
Modular units without base or column for automation applications
Rotary turntables and additional automation available
Post cooling system
Part Hold Down Plungers
Each probe

BY096 - Adjustable 2030MZ Unit (2 Zones, No Probes)
