Description
|
| Part number | 8941077352 | |
| Model | CP7735H | |
| Out of production | Out of production | |
| Handle type | Pistol | |
| Square drive | 1/2" | |
| Working Torque Range (fwd) | 22-221 ft.lbs | 30-300 |
| Maximum Torque (reverse) | 300 ft.lbs | 407 Nm |
| Free speed | 10000 rpm | |
| Weight | 2.6 lb | 1.2 kg |
| Length | 5.7" | 145 mm |
| Actual air consumption | 15 cfm | |
| Air inlet thread size | 1/4 in. | |
| Noise level | 95 db(A) | |
| Sound Power | 106 db(A) | |
| Vibration (ISO-8662-7) | 3.9 m/s² | |
| Vibration α (ISO-28927-2) | 4.9 m/s² | |
| Vibration K (ISO-28927-2) | 1.6 m/s² | |
| Socket retainer | Friction ring  Click to enlarge | |
| Clutch type | Twin hammer  Click to enlarge | |
