Description
Direct drive multi-vane air motors from 0.75 hp to 10.5 hp with speed adjustability through air controls.
Features
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive environments.
- Instantly reversible.
- Compact and portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean air supply and proper lubrication.
- No shock starts: Air cushioned start-up cuts stress on your equipment.
- Mounting options: Face and foot mount.
| Model | Max Power hp | Speed at Max. Power (rpm) | Free Speed (rpm) | Starting Torque lb.-ft. | Stall Torque (ft.-lb.) | Air Consumption at Max. Power (scfm) | Weight lb. |
|---|---|---|---|---|---|---|---|
| MVA017A | 1.93 | 2800 | 5450 | 4.5 | 7 | 76 | 12.5 |
| MVA017B | 1.93 | 2800 | 5450 | 4.5 | 7 | 76 | 12.5 |
| MVA034A | 4.15 | 3000 | 6250 | 8.3 | 12.8 | 181 | 16.5 |
| MVA034B | 4.15 | 3000 | 6250 | 8.3 | 12.8 | 181 | 16.5 |
| MOV005AA | 0.75 | 3300 | 6800 | 1.65 | 2.2 | 30 | 6.5 |
| MOV075AA | 10.5 | 2600 | 5600 | 22.5 | 30 | 260 | 64 |
