Description
The QE4S Series of In-Line hand-held tools when teamed with the IC Series Controllers provide superior accuracy and durability to meet your fastening requirements where a straight or In-line tool is required. The QE4S offer a torque range from 2.0 to 25 Nm with speeds up to 1820 RPM. Easy controls, Selector Switch, comfortable grips and bright LEDs allow the operators to focus on their work. The non-contacting switches, heavy duty gear train and DC brushless motor create a durable package that will keep your maintenance cost down. The small size, high speed, ergonomic grip and easy accessible controls will help keep your production line running smoothly.
Productivity
- Faster speeds at torque than competitive tools
- Automatic tool identification means any Insight controller can instantly recognize any QE tool — without manual entry of tool torque range, motor charcteristics, or transducer values
- Improved accuracy with Sine Drive technology
- Programmable momentary switch
- Optimum flexibility through modular designs
- Patented TactAlert provides the operator with tactile feedback of a tool fault or NOK signal through gentle mechanical oscillation in the grip surface, reducing reliance on visual or audible signals
Ergonomics
- Compact, lightweight designs
- Comfortable grip surfaces and smooth contours
- Low-force triggers and rotary reverse switches
Reliability
- Digital link between tool and controller
- Durable chassis
- Non-contacting switches
- Two-year standard warranty on all tool cables
- High free speed
- Compact lightweight design
- High duty cycle
- Status lights
- Non-contacting switches
- Trigger or lever start
- Rotary reverse switch
- Durable flexible cables
- 3, 6, and 10 meter tool cable lengths ..... Straight or 90 degree versions
- 10, 20 and 40 meter extensions cables
- Socket trays
- Selector switches
- ICS Software
- Suspension bails
- Torque arms and tubes
Tool
Cables
Accessories
Model | CPN | Free Speed rpm | Max Torque Nm | Torque Range Nm |
QE4ST010R20Q04 | 10561660 | 1820 | 10 | 2.0-8.0 |
QE4ST010R20S04 | 10561702 | 1820 | 10 | 2.0-8.0 |
QE4ST010R20S06 | 10561751 | 1820 | 10 | 2.0-8.0 |
QE4ST010R21Q04 | 10561769 | 1820 | 10 | 2.0-8.0 |
QE4ST010R21S04 | 10562007 | 1820 | 10 | 2.0-8.0 |
QE4ST010R21S06 | 10562031 | 1820 | 10 | 2.0-8.0 |
QE4ST010R21S08 | 10562122 | 1820 | 10 | 2.0-8.0 |
QE4ST010R41Q04 | 10562148 | 1820 | 10 | 2.0-8.0 |
QE4ST010R41S04 | 10562296 | 1820 | 10 | 2.0-8.0 |
QE4ST010R41SO6 | 10562304 | 1820 | 10 | 2.0-8.0 |
QE4ST010R41S08 | 10562312 | 1820 | 10 | 2.0-8.0 |
QE4ST015R20Q04 | 10562320 | 1220 | 15 | 3.0-12.0 |
QE4ST015R20S04 | 10562429 | 1220 | 15 | 3.0-12.0 |
QE4ST015R20S06 | 10562437 | 1220 | 15 | 3.0-12.0 |
QE4ST015R21Q04 | 10562445 | 1220 | 15 | 3.0-12.0 |
QE4ST015R21S04 | 10562452 | 1220 | 15 | 3.0-12.0 |
QE4ST015R21S06 | 10562544 | 1220 | 15 | 3.0-12.0 |
QE4ST015R21S08 | 10562551 | 1220 | 15 | 3.0-12.0 |
QE4ST015R41Q04 | 10562692 | 1220 | 15 | 3.0-12.0 |
QE4ST015R41S04 | 10562981 | 1220 | 15 | 3.0-12.0 |
QE4ST015R41S06 | 10563013 | 1220 | 15 | 3.0-12.0 |
QE4ST015R41S08 | 10563021 | 1220 | 15 | 3.0-12.0 |
QE4ST020R20QO4 | 10563229 | 900 | 20 | 4.0-16.0 |
QE4ST020R20S04 | 10563237 | 900 | 20 | 4.0-16.0 |
QE4ST020R20S06 | 10563245 | 900 | 20 | 4.0-16.0 |
QE4ST020R21Q04 | 10563252 | 900 | 20 | 4.0-16.0 |
QE4ST020R21S04 | 10563419 | 900 | 20 | 4.0-16.0 |
QE4ST020R21S06 | 10563427 | 900 | 20 | 4.0-16.0 |
QE4ST020R21SO8 | 10563435 | 900 | 20 | 4.0-16.0 |
QE4ST020R41Q04 | 10563443 | 900 | 20 | 4.0-16.0 |
QE4ST020R41S04 | 10563450 | 900 | 20 | 4.0-16.0 |
QE4ST020R41S06 | 10563468 | 900 | 20 | 4.0-16.0 |
QE4ST020R41S08 | 10563492 | 900 | 20 | 4.0-16.0 |
QE4ST025R20Q04 | 10563500 | 710 | 25 | 5.0-20.0 |
QE4ST025R20S04 | 10563518 | 710 | 25 | 5.0-20.0 |
QE4ST025R20S06 | 10563542 | 710 | 25 | 5.0-20.0 |
QE4ST025R21Q04 | 10563559 | 710 | 25 | 5.0-20.0 |
QE4ST025R21S04 | 10563567 | 710 | 25 | 5.0-20.0 |
QE4ST025R21S06 | 10563609 | 710 | 25 | 5.0-20.0 |
QE4ST025R21S08 | 10563708 | 710 | 25 | 5.0-20.0 |
