IR Ingersoll Rand QE4 Series Push to Start Nutsetters

The QE4T Push to Start tool offers operators an additional level of comfort and enhanced productivity. With its Hall Effect switch on the output spindle, the tool is activated when the operator presses down on the fastener, eliminating the need to press a lever or switch. When used with the I-R EZ Tool Arm the tool becomes both weightless and reaction less to the operator. The QE4T is available in a torque range from 2.0 to 25 Nm with speeds up to 1820 RPM. It is available in both Quick Change and square drives. Easy reverse control, Selector Switch, comfortable grips and bright LEDs allow the operators to focus on their work. The non-contacting switches, heavy duty gear train and DC brushless motor create a durable package that will keep your maintenance cost down. The small size, high speed, ergonomic grip and easy accessible controls will help keep your production line running smoothly.

Productivity

• Faster speeds at torque than competitive tools
• Automatic tool identification means any Insight controller can instantly recognize any QE tool — without manual entry of tool torque range, motor charcteristics, or transducer values
• Improved accuracy with Sine Drive technology
• Programmable momentary switch
• Optimum flexibility through modular designs
• Patented TactAlert provides the operator with tactile feedback of a tool fault or NOK signal through gentle mechanical oscillation in the grip surface, reducing reliance on visual or audible signals

• Compact, lightweight designs
• Comfortable grip surfaces and smooth contours
• Low-force triggers and rotary reverse switches

Reliability

• Digital link between tool and controller
• Durable chassis
• Non-contacting switches
• Two-year standard warranty on all tool cables



Tool

• High free speed
• Compact lightweight design
• High duty cycle
• Status lights
• Non-contacting switches
• Trigger or lever start
• Rotary reverse switch



Cables

• Durable flexible cables
• 3, 6, and 10 meter tool cable lengths ..... Straight or 90 degree versions
• 10, 20 and 40 meter extensions cables



Accessories

• Socket trays
• Selector switches
• ICS Software
• Suspension bails
• Torque arms and tubes





Model	CPN	Free Speed rpm	Max Torque Nm	Weight kg	Torque Range Nm
QE4TS010R11Q04	16678955	1820	10	1.2	2.0-8.0
QE4TS010R11S04	16678963	1820	10	1.2	2.0-8.0
QE4TS010R11S06	16678971	1820	10	1.2	2.0-8.0
QE4TS015R11S04	16678989	1220	15	1.2	3.0-12.0
QE4TS015R11S06	16678997	1220	15	1.2	3.0-12.0
QE4TS020R11S04	16679003	900	20	1.2	4.0-16
QE4TS020R11S06	16679011	710	25	1.2	5.0-20.0
QE4TS025R11S04	80175938	710	25	1.2	5.0-20.0
QE4TS025R11S06	16679011	710	25	1.2	5.0-20.0
