Description
| Model | 1RLMC1 |
| Side to Center Distance (mm) | 14 |
| Torque Range (soft joint) (Nm) | 0.30 - 2.25 |
| Length (mm) | 233 |
| Length (in) | 9.19 |
| Air Inlet | 1/8" NPT |
| Side to Center Distance (in) | 0.55 |
| Weight (kg) | 0.51 |
| Actuation | Lever Start |
| Spindle Type | 1/4" QC |
| Weight (lb.) | 1.13 |
| Free Speed (rpm) | 1650 |
| Torque Range (soft joint) (in.-lb.) | 2.5 - 20.0 |
Quality and Performance at an Affordable Price.1 Series Adjustable Cushion clutch screwdrivers combine proven quality and performance with economy for a variety of light assembly applications.
- Lightweight with coated grips for easy handling.
- Torque Range: 1.5 to 30.0 in.-lbs / 0.15 to 3.4 Nm
- Speeds: 1000 to 1650 RPM
- Specification tables include examples of our most popular models.
For more information on the Ingersoll Rand 1RLMC1 please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4724548
