Description
- Operates on 220 or 480 volt, 3-phase
- Full 360-degree movement
- Variable 2-speed motor
- Includes 5 free tap holders (up to 7/8") and/or reducers
- Tap capacity up to 1 1/4": #6 to 5/8" at 300 rpm, 5/8" to 1 1/4" at 70 rpm
- Working range 20-76 in; 51-193 cm
- Size 3 Quick Change Chuck
Model | Description | Working Range | Speed | Size | ||||||||||
GH-30 | GH-30 Hydraulic Tapper with variable 2-speed motor, up to 1-1/4" capacity in steel, size 3 Quick Change Chuck | 20 to 76 in | Variable 2-speed motor (375 max. rpm) | Up to 1 1/4 in | ||||||||||
GHM-30 | GHM-30 Hydraulic Multi-position head Tapper with variable 2-speed motor, up to 1-1/4" capacity in steel, size 3 Quick Change Chuck | 20 to 76 in | Variable 2-speed motor (375 max. rpm) | Up to 1 1/4 in |
*Tap capacities are for mild steel at 2" max depth using a standard US inch or US metric tap
