Description
22N Series, Multi-vane Air Motor. 1.75 hp (1.31 Kw). 275 rpm with built in governor for maximum speed control. Torque adjustability through air controls.
Features
- Governed motors for improved speed control
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive applications.
- Instantly reversible: A four-way valve allows instant motor reversal (on reversible units) with the turn of a valve.
- Cool Running: A running air motor expands air, allowing motors to operate in temperatures up to 150oF and some motors up to 300oF with special grease, lube and seals.
- Compact and Portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean, dry, lubricated air supply.
- No shock starts: Air cushioned start-up cuts stress to your equipment.
| Model | Starting Torque lb.-ft. | Weight lb. | Speed at Max. Power (rpm) | Air Consumption at Max. Power (scfm) | Free Speed rpm | Stall Torque lb.-ft. | Max. Power hp |
|---|---|---|---|---|---|---|---|
| 22N51-W/RC | 49 | 21 | 208 | 55 | 280 | 66 | 1.75 |
