Description
000 Series, In-Line planetary gear, Multi-vane Air Motors. Fractional horsepower, 0.25 hp (0.186 Kw). 300 rpm to 20,000 rpm with adjustability through air controls. Stackable gearing allows additional gear reductions.
Features
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive applications.
- Instantly reversible: A four-way valve allows instant motor reversal (on reversible units) with the turn of a valve.
- Cool Running: A running air motor expands air, allowing motors to operate in temperatures up to 150oF and some motors up to 300oF with special grease, lube and seals.
- Compact and Portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean, dry, lubricated air supply.
- No shock starts: Air cushioned start-up cuts stress to your equipment.
- Options for thread on Male Square adapters, Hex ball adapters and Drill chucks
- Exhaust manifold and muffler rotates 360 degrees
- Flange Bracket Option
- Foot Bracket Option
| Model | Air Consumption at Max. Power (scfm) | Free Speed rpm | Weight lbs. | Spindle | Sound Level @ Free Speed dB(A) | Reversible | Torque Output @ Max. H.P. (lb. ft.) | Torque Stall (lb.ft.) | Load Speed @ Max. H.P. (Rpm) | Gear Reduction |
|---|---|---|---|---|---|---|---|---|---|---|
| 7538-B | 18.1 | 550 | 1.82 | 3/8" Keyed | 75 | No | 4.0 | 8.2 | 325 | Double |
| 7539-B | 18.1 | 900 | 1.82 | 3/8" Keyed | 75 | No | 2.4 | 5.0 | 550 | Double |
| 7540-B | 18.1 | 2,700 | 1.52 | 3/8" Keyed | 75 | No | .82 | 1.75 | 1,600 | Single |
| 7541-B | 18.1 | 4,500 | 1.52 | 3/8" Keyed | 75 | No | .49 | 1.05 | 2,700 | Single |
| 7542-C | 18.1 | 20,000 | 1.52 | 3/8" Keyed | 75 | No | .11 | .22 | 12,000 | Single |
| 7533-B | 18.1 | 550 | 1.82 | 3/8" Threaded | 75 | No | 4.0 | 8.2 | 325 | Double |
| 7534-B | 18.1 | 900 | 1.82 | 3/8" Threaded | 75 | No | 2.4 | 5.0 | 550 | Double |
| 7535-C | 18.1 | 2,700 | 1.52 | 3/8" Threaded | 75 | No | .82 | 1.75 | 1,600 | Single |
| 7536-B | 18.1 | 4,500 | 1.52 | 3/8" Threaded | 75 | No | .49 | 1.05 | 2,700 | Single |
| 7537-C | 18.1 | 20,000 | 1.52 | 3/8" Threaded | 75 | No | 11 | .22 | 12,000 | Single |
| 7543-B | 20.0 | 550 | 1.82 | 3/8" Keyed | 75 | Yes | 4.37 | 7.80 | 300 | Double |
| 7544-B | 20.0 | 900 | 1.82 | 3/8" Keyed | 75 | Yes | 2.62 | 4.75 | 550 | Double |
| 7545-B | 20.0 | 2,700 | 1.52 | 3/8" Keyed | 75 | Yes | .87 | 1.60 | 1,500 | Single |
| 7546-B | 20.0 | 4,500 | 1.52 | 3/8" Keyed | 75 | Yes | .55 | .98 | 2,400 | Single |
| 7547-C | 20.0 | 20,000 | 1.52 | 3/8" Keyed | 75 | Yes | .12 | .22 | 11,000 | Single |
