Description
1801 and 1841 Series, In-Line planetary gear, Multi-vane Air Motors. 1.10 hp to 1.40 hp; 150 rpm to 1990 rpm with adjustability through air controls.
Features
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive applications. Instantly reversible: A four-way valve allows instant motor reversal (on reversible units) with the turn of a valve.
- Cool Running: A running air motor expands air, allowing motors to operate in temperatures up to 150oF and some motors up to 300oF with special grease, lube and seals.
- Compact and Portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean, dry, lubricated air supply.
- No shock starts: Air cushioned start-up cuts stress to your equipment.
- Two hole face mount standard
- Optional ¾ npt piped away exhaust option available
- Square drive option available
| Model | Starting Torque lb.-ft. | Weight lb. | Speed at Max. Power (rpm) | Air Consumption at Max. Power (scfm) | Free Speed rpm | Stall Torque lb.-ft. | Max. Power hp |
|---|---|---|---|---|---|---|---|
| 1801N | 10.5 | 5-3/8 | 918 | 46 | 1990 | 14 | 1.40 |
| 1801P | 17.2 | 5-3/4 | 500 | 46 | 1050 | 23 | 1.35 |
| 1801Q | 30.0 | 5-3/4 | 300 | 46 | 650 | 40 | 1.35 |
| 1801U | 41.0 | 5-3/4 | 205 | 46 | 435 | 55 | 1.35 |
| 1801W | 52.0 | 5-3/4 | 175 | 46 | 370 | 70 | 1.35 |
| 1841N | 9.3 | 5-1/2 | 800 | 43 | 1700 | 12.5 | 1.2 |
| 1841P | 15.0 | 5-7/8 | 430 | 43 | 900 | 20.0 | 1.1 |
| 1841Q | 27.0 | 5-7/8 | 260 | 43 | 550 | 36.0 | 1.1 |
| 1841U | 37.0 | 5-7/8 | 175 | 43 | 380 | 50.0 | 1.1 |
| 1841W | 45.0 | 5-7/8 | 150 | 43 | 320 | 60.0 | 1.1 |
