Description
|
| Part number | 6151909521 | |
| Model | CP9521 | |
| Out of production | Out of production | |
| Handle type | Pistol | |
| Square drive | 3/8" | |
| Working Torque Range (fwd) | 5-50 ft.lbs | 7-68 |
| Maximum Torque (reverse) | 75 ft.lbs | 102 Nm |
| Free speed | 11000 rpm | |
| Blows per minute | 1620 | |
| Weight | 2.6 lb | 1.2 kg |
| Length | 5.75" | 146 mm |
| Actual air consumption | 10 cfm | |
| Air inlet thread size | 1/4 in. | |
| Noise level | 87 db(A) | |
| Sound Power | 98 db(A) | |
| Vibration (ISO-8662-7) | 4.9 m/s² | |
| Vibration α (ISO-28927-2) | 4.7 m/s² | |
| Vibration K (ISO-28927-2) | 3.3 m/s² | |
| Socket retainer | Friction ring  Click to enlarge | |
| Clutch type | Rocking dog  Click to enlarge | |
