IR Ingersoll Rand Series 34 Electric / Pneumatic Self Feed Drills 0.33 H.P. ( .25 kW )

Ingersoll Rand

SKU:
IR34SFD
Availability:
Please Call For Pricing and Availability
Please Call For Pricing and Availability

Description

  • A precision spindle with pre-loaded bearing support for accurate targeting, longevity, and .001 t.i.r. runout, or less.
  • Built-in dwell control that holds repeatable depth within .002 inches.
  • Individually adjustable feed rate control for advance and retract.
  • The longest usable tool stroke length (adjustable to 110 mm [4.33 inches]) available in such a compact tool.
  • Variable thrust from 150 to 330 lbs. for proper penetration power and rate.
  • A heavy duty, ball-bearing supported drive train that is fully sealed and prelubed.
  • Air and electric I/Os for control and feedback.




    • CLICK HERE to view

    IR Ingersoll Rand Fixtured Drill Selection PDF Catalog



    Series 34 Electric / Pneumatic Self-Feed Drill Model Listing

    Model

    Torque Peak HP.P. LB.FT.

    Med. Wood or F.R.P.

    Load Speed Peak H.P. R.P.M.

    Free Speed rpm

    Nominal Drilling Capacities Steel SAE 1213

    FE034A-77B-A

    0.23

    .078/.096

    7013

    7690

    .036/.040

    FE034A-67B-A

    0.26

    .096/.110

    6155

    6750

    .040/.046

    FE034A-59B-A

    0.30

    .110/.125

    5486

    5954

    .046/.052

    FE034A-54B-A

    0.33

    .125/.140

    4977

    5400

    .052/.059

    FE034A-48B-A

    0.38

    .140/.156

    4470

    4800

    .059/.063

    FE034A-43B-A

    0.42

    .156/.187

    3979

    4274

    .063/.073

    FE034A-38B-A

    0.47

    .187/.209

    3582

    3808

    .073/.082

    FE034A-34B-A

    0.53

    .209/.234

    3197

    3398

    .082/.093

    FE034A-30B-A

    0.60

    .234/.265

    2851

    3030

    .093/.104

    FE034A-27B-A

    0.67

    .265/.281

    2566

    2700

    .104/.116

    FE034A-24B-A

    0.75

    .281/.312

    2279

    2400

    .116/.128

    FE034A-22B-A

    0.83

    .312/.343

    2070

    2178

    .128/.147

    FE034A-19B-A

    0.94

    .343/.390

    1822

    1920

    .147/.164

    FE034A-17B-A

    1.07

    .390/.406

    1600

    1685

    .164/.187

    FE034A-38C-A

    0.47

    .187/.209

    3507

    3845

    .073/.082

    FE034A-34C-A

    0.53

    .209/.234

    3078

    3375

    .082/.093

    FE034A-30C-A

    0.60

    .234/.265

    2744

    2977

    .093/.104

    FE034A-27C-A

    0.67

    .265/.281

    2488

    2700

    .104/.116

    FE034A-24C-A

    0.75

    .281/.312

    2235

    2400

    .116/.128

    FE034A-22C-A

    0.83

    .312/.343

    1990

    2137

    .128/.147

    FE034A-19C-A

    0.94

    .343/.390

    1791

    1904

    .147/.164

    FE034A-17C-A

    1.07

    .390/.406

    1598

    1699

    .164/.187

    FE034A-15C-A

    1.20

    .406/.421

    1426

    1516

    .187/.204

    FE034A-14C-A

    1.34

    .421/.437

    1283

    1350

    .204/.234

    FE034A-12C-A

    1.50

    .437/.453

    1139

    1199

    .234/.250

    FE034A-11C-A

    1.66

    .453/.468

    1034

    1089

    .250/.265

    FE034A-10C-A

    1.88

    .468/.484

    911

    959

    .265/.281

    FE034A-08C-A

    2.14

    .484/.531

    800

    842

    .281/.312
