Description
- A precision spindle with pre-loaded bearing support for accurate targeting, longevity, and .001 t.i.r. runout, or less.
- Built-in dwell control that holds repeatable depth within .002 inches.
- Individually adjustable feed rate control for advance and retract.
- The longest usable tool stroke length (adjustable to 110 mm [4.33 inches]) available in such a compact tool.
- Variable thrust from 150 to 330 lbs. for proper penetration power and rate.
- A heavy duty, ball-bearing supported drive train that is fully sealed and prelubed.
- Air and electric I/Os for control and feedback.
IR Ingersoll Rand Fixtured Drill Selection PDF Catalog
Series 74 Electric / Pneumatic Self-Feed Drill Model Listing | ||||||
Model | Torque Peak HP.P. LB.FT. | Med. Wood or F.R.P. | Load Speed Peak H.P. R.P.M. | Free Speed rpm | Nominal Drilling Capacities Steel SAE 1213 | |
FE074B-77(B or D)-A | 0.48 | .078/.109 | 7013 | 7690 | .046/.055 | |
FE074B-67(B or D)-A | 0.54 | .109/.140 | 6155 | 6750 | .055/.062 | |
FE074B-59(B or D)-A | 0.62 | .140/.187 | 5486 | 5954 | .062/.070 | |
FE074B-54(B or D)-A | 0.69 | .187/.250 | 4977 | 5400 | .070/.084 | |
FE074B-48(B or D)-A | 0.77 | .250/.312 | 4470 | 4800 | .084/.090 | |
FE074B-43(B or D)-A | 0.86 | .312/.375 | 3979 | 4274 | .090/.101 | |
FE074B-38(B or D)-A | 0.98 | .375/.437 | 3582 | 3808 | .101/.112 | |
FE074B-34(B or D)-A | 1.08 | .437/.468 | 3197 | 3398 | .112/.125 | |
FE074B-30(B or D)-A | 1.22 | .468/.500 | 2851 | 3031 | .125/.140 | |
FE074B-27(B or D)-A | 1.37 | .500/.531 | 2566 | 2700 | .140/.156 | |
FE074B-24(B or D)-A | 1.55 | .531/.562 | 2279 | 2398 | .156/.187 | |
FE074B-22(B or D)-A | 1.70 | .562/.593 | 2070 | 2178 | .187/.203 | |
FE074B-19(B or D)-A | 1.92 | .593/.625 | 1822 | 1918 | .203/.218 | |
FE074B-17(B or D)-A | 2.19 | .625/.656 | 1600 | 1684 | .218/.234 | |
FE074B-38(C or E)-A | 0.98 | .375/.437 | 3507 | 3845 | .101/.112 | |
FE074B-34(C or E)-A | 1.08 | .437/.468 | 3078 | 3375 | .112/.125 | |
FE074B-30(C or E)-A | 1.22 | .468/.500 | 2744 | 2977 | .125/.140 | |
FE074B-27(C or E)-A | 1.37 | .500/.531 | 2488 | 2700 | .140/.156 | |
FE074B-24(C or E)-A | 1.55 | .531/.562 | 2235 | 2400 | .156/.187 | |
FE074B-22(C or E)-A | 1.70 | .562/.593 | 1990 | 2137 | .187/.203 | |
FE074B-19(C or E)-A | 1.92 | .593/.625 | 1791 | 1904 | .203/.218 | |
FE074B-17(C or E)-A | 2.19 | .625/.656 | 1598 | 1699 | .218/.265 | |
FE074B-15(C or E)-A | 2.43 | .656/.687 | 1426 | 1516 | .265/.315 | |
FE074B-14(C or E)-A | 2.73 | .687/.718 | 1283 | 1350 | .315/.343 | |
FE074B-12(C or E)-A | 3.08 | .718/.750 | 1139 | 1199 | .343/.375 | |
FE074B-11(C or E)-A | 3.39 | .750/.781 | 1034 | 1089 | .375/.437 | |
FE074B-10(C or E)-A | 3.84 | .781/.812 | 911 | 959 | .437/.500 | |
FE074B-08(C or E)-A | 4.38 | .812/.875 | 800 | 842 | .500/.531 | |
