Description
- A precision spindle with pre-loaded bearing support for accurate targeting, longevity, and .001 t.i.r. runout, or less.
- Built-in dwell control that holds repeatable depth within .002 inches.
- Individually adjustable feed rate control for advance and retract.
- The longest usable tool stroke length (adjustable to 110 mm [4.33 inches]) available in such a compact tool.
- Variable thrust from 150 to 330 lbs. for proper penetration power and rate.
- A heavy duty, ball-bearing supported drive train that is fully sealed and prelubed.
- Air and electric I/Os for control and feedback.
IR Ingersoll Rand Fixtured Drill Selection PDF Catalog
Series 54 Electric / Pneumatic Self-Feed Drill Model Listing | ||||||
Model | Med. Wood or F.R.P. | Load Speed Peak H.P. R.P.M. | Free Speed rpm | Nominal Drilling Capacities Steel SAE 1213 | Torque, Peak H.P. LB. FT. | |
FE054C-77(B or D)-A | .078/.096 | 7013 | 7690 | .036/.046 | 0.32 | |
FE054C-67(B or D)-A | .096/.125 | 6155 | 6750 | .046/.055 | 0.36 | |
FE054C-59(B or D)-A | .125/.140 | 5486 | 5954 | .0555/.062 | 0.41 | |
FE054C-54(B or D)-A | .140/.156 | 4977 | 5400 | .062/.073 | 0.46 | |
FE054C-48(B or D)-A | .156/.187 | 4470 | 4800 | .073/.081 | 0.51 | |
FE054C-43(B or D)-A | .187/.228 | 3979 | 4274 | .081/.086 | 0.57 | |
FE054C-38(B or D)-A | .228/.250 | 3582 | 3808 | .086/.093 | 0.65 | |
FE054C-34(B or D)-A | .250/.281 | 3197 | 3398 | .093/.101 | 0.72 | |
FE054C-30(B or D)-A | .281/.312 | 2851 | 3031 | .101/.110 | 0.81 | |
FE054C-27(B or D)-A | .312/.343 | 2566 | 2700 | .110/.125 | 0.91 | |
FE054C-24(B or D)-A | .343/.375 | 2279 | 2398 | .125/.138 | 1.03 | |
FE054C-22(B or D)-A | .375/.406 | 2070 | 2178 | .138/.156 | 1.13 | |
FE054C-19(B or D)-A | .406/.437 | 1822 | 1918 | .156/.187 | 1.28 | |
FE054C-17(B or D)-A | .437/.484 | 1600 | 1684 | .187/.250 | 1.46 | |
FE054C-38(C or E)-A | .228/.250 | 3507 | 3845 | .086/.093 | 0.65 | |
FE054C-34(C or E)-A | .250/.281 | 3078 | 3375 | .093/.101 | 0.72 | |
FE054C-30(C or E)-A | .281/.312 | 2744 | 2977 | .101/.110 | 0.81 | |
FE054C-27(C or E)-A | .312/.343 | 2488 | 2700 | .110/.125 | 0.91 | |
FE054C-24(C or E)-A | .343/.375 | 2235 | 2400 | .125/.138 | 1.03 | |
FE054C-22(C or E)-A | .375/.406 | 1990 | 2137 | .138/.156 | 1.13 | |
FE054C-19(C or E)-A | .406/.437 | 1791 | 1904 | .156/.187 | 1.28 | |
FE054C-17(C or E)-A | .437/.484 | 1598 | 1699 | .187/.250 | 1.46 | |
FE054C-15(C or E)-A | .484/.531 | 1426 | 1516 | .250/.281 | 1.62 | |
FE054C-14(C or E)-A | .531/.562 | 1283 | 1350 | .281/.312 | 1.82 | |
FE054C-12(C or E)-A | .562/.593 | 1139 | 1199 | .312/.343 | 2.05 | |
FE054C-11(C or E)-A | .593/.625 | 1034 | 1089 | .343/.359 | 2.26 | |
FE054C-10(C or E)-A | .625/.656 | 911 | 959 | .359/.375 | 2.56 | |
FE054C-08(C or E)-A | .656/.687 | 800 | 842 | .375/.390 | 2.92 | |
