Description
ARO Hi-Thrust Drills feature a dual piston which develops the increased thrust for fast penetration and reduced cycle times. The tools are fully automatic, with all cycle and motor functions regulated by a single control module. They are easily installed, requiring only simple pneumatic circuity. Hi-Thrust Drills can also be used in conjunction with other pneumatic and electric ARO Automatic Production tools.
- Adjustable hydraulic check provides positive feed rate control for fine adjustment of chip size or breakthrough control.
- "Dead stop" and "dwell" control offer repeatable depth accuracy within .001"
- Heavy-duty cast iron housing for rigid mounting.
- Constant tool length, regardless of spindle speed, allows speed change without repositioning the tool.
- Both coarse and fine stroke length adjustments enables quick, accurate setups.
- Control module ia s complete, replaceable unit and can be easily removed without tool disassembly.
- Modular motor and gearing units enable fast, easy speed changes and servicing.
- Single exterior lubrication point for entire gear train simplifies preventative maintenance.
- Muffled exhaust for a more comfortable work environment.
- Exhaust may be piped away.
Model | Sound Level dB(A) | Thrust @ 90 PSI lb. (N) | Free Speed rpm | Std. Chuck Capacity in. (mm) | Stroke Length in. (mm) | |||||
8670-47-3 | 80 | 500 lbs. | 4,700 | 3/4" ( 19mm ) | 3.0 ( 76 ) | |||||
8670-28-3 | 80 | 500 lbs. | 2,800 | 3/4" ( 19mm ) | 3.0 ( 76 ) | |||||
8670-13-3 | 80 | 500 lbs. | 1,350 | 3/4" (19mm) | 3.0 (76) | |||||
8670-8-3 | 80 | 500 lbs. | 800 | 3/4" ( 19mm ) | 3.0 ( 76 ) | |||||
8670-4-3 | 80 | 500 lbs. | 450 | 3/4" ( 19mm ) | 3.0 ( 76 ) |
