Description
| Model | 8683-BPR-D |
| Stall Torque (in.-lbs) | 50 |
| Torque Range Soft Draw Nm | |
| Free Speed rpm | 750 |
| Spindle Offset in. | .8 |
| Stall Torque Nm | 5.7 |
| Air Consp. @ Free Speed L/s | 8.0 |
| Tool Length mm | 152 |
| Sound Level dB(A) @ Free Speed | 82 |
| Torque Range Soft Draw in-lbs | |
| Weight lb | 1.6 |
| Tool Weight kg | .7 |
| Spindle Offset mm | 20 |
| Air Consp. @ Free Speed cfm | 17 |
| Length in. | 6.0 |
Torque output: 15 to 50 in.-lbs ( 1.7 to 5.7 Nm ) Quick Reverse Trigger - Direct Drive
- Recommended for soft pull applications not requiring critical torque control.
For more information on the Ingersoll Rand 8683-BPR-D please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4164612
