Description
| Model | 8684-BPR-D |
| Stall Torque (in.-lbs) | 15 |
| Torque Range Soft Draw Nm | |
| Free Speed rpm | 2300 |
| Spindle Offset in. | .8 |
| Stall Torque Nm | 1.7 |
| Air Consp. @ Free Speed L/s | 10.8 |
| Tool Length mm | 123 |
| Sound Level dB(A) @ Free Speed | 82 |
| Torque Range Soft Draw in-lbs | |
| Weight lb | 1.3 |
| Tool Weight kg | .6 |
| Spindle Offset mm | 20 |
| Air Consp. @ Free Speed cfm | 23 |
| Length in. | 4.8 |
Torque output: 15 to 50 in.-lbs ( 1.7 to 5.7 Nm ) Quick Reverse Trigger - Direct Drive
- Recommended for soft pull applications not requiring critical torque control.
For more information on the Ingersoll Rand 8684-BPR-D please call AirToolPro / Zampini Industrial Group at 1-800-353-4676
CCN Number 4164653
