Description
3800 and 3840 Series, In-Line planetary gear, Multi-vane Air Motors. 1.35 hp to 1.55 hp (1.01 to 1.16 Kw). 83 rpm to 1100 rpm with adjustability through air controls.
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive applications.
- Instantly reversible: A four-way valve allows instant motor reversal (on reversible units) with the turn of a valve.
- Cool Running: A running air motor expands air, allowing motors to operate in temperatures up to 150oF and some motors up to 300oF with special grease, lube and seals.
- Compact and Portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean, dry, lubricated air supply.
- No shock starts: Air cushioned start-up cuts stress to your equipment
- Six hole face mount standard
- Optional ¾ npt piped away exhaust option available
- Square drive option available
Model | Starting Torque lb.-ft. | Weight lb. | Speed at Max. Power (rpm) | Air Consumption at Max. Power (scfm) | Free Speed rpm | Stall Torque lb.-ft. | Max. Power hp |
---|---|---|---|---|---|---|---|
3800M | 24 | 7-1/8 | 520 | 48 | 1100 | 33 | 1.55 |
3800P | 42 | 8-1/2 | 285 | 48 | 600 | 56.5 | 1.45 |
3800Q | 62 | 8-1/2 | 180 | 48 | 375 | 83.5 | 1.45 |
3800R | 72 | 8-1/2 | 150 | 48 | 320 | 96 | 1.45 |
3800S | 88 | 8-1/2 | 120 | 48 | 255 | 118 | 1.45 |
3800U | 105 | 8-1/2 | 105 | 48 | 220 | 140 | 1.45 |
3840M | 23 | 7-3/8 | 390 | 44 | 825 | 31.5 | 1.40 |
3840P | 40 | 8-3/4 | 215 | 44 | 440 | 53..5 | 1.35 |
3840Q | 60 | 8-3/4 | 130 | 44 | 280 | 80 | 1.35 |
3840R | 69 | 8-3/4 | 122 | 44 | 238 | 92 | 1.35 |
3840S | 86 | 8-3/4 | 100 | 44 | 190 | 115 | 1.35 |
3840U | 100 | 8-3/4 | 83 | 44 | 162 | 134 | 1.35 |
