Description
Direct drive multi vane air motors, 0.33 hp to 4.8 hp with speed adjustability through air controls.
Features
- Lube Free airline operation for most applications.
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive applications.
- Instantly reversible.
- Compact and portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean air supply.
- No shock starts: Air cushioned start-up cuts stress to your equipment.
- Mounting options: NEMA flange, face, and foot mount.
| Model | Max Power hp | Speed at Max. Power (rpm) | Starting Torque lb.-ft. | Stall Torque (ft.-lb.) | Weight (lb) |
|---|---|---|---|---|---|
| SM1AM | 0.33 | 7600 | 0.29 | 0.38 | 1.5 |
| SM1UP | 0.60 | 6000 | 0.45 | 0.6 | 1.75 |
| SM2AM | 0.88 | 3000 | 1.7 | 2.3 | 7.5 |
| SM4AM | 1.5 | 3000 | 2.6 | 4.1 | 8.25 |
| SM6AM | 3.6 | 3000 | 5.3 | 8.7 | 16.25 |
| SM8AM | 4.8 | 2500 | 10 | 14 | 22.5 |
